Cambridge Audio AXR100 Stereo Receiver

Color: Grey

GreyGrey

Product variants

FM/AM Stereo Receiver

With 100 Watts of power and an FM/AM tuner, the AXR100 is designed to deliver high-quality sound and even more power across radio, vinyl or streaming.

Your journey into sound

AXR100 is a powerful receiver aimed at listening to music, and appreciating how it’s been recorded, from a variety of sources – including its own integrated tuner.

Streaming is easy

Thanks to Bluetooth 5.0, it's simple to stream music from your phone, laptop, or other compatible device. It’s easier than ever to discover and share music.

Built-in MM Phono Stage

A built-in moving magnet phono stage means you can plug a turntable straight in, no extra kit needed. Soon you’ll be playing the records you already own and planning your next purchases.

Uninterrupted listening

With a built-in FM/AM tuner, the AXR100 is the perfect amplifier for lovers of live radio. Programme up to 40 stations to tune in instantly, with station information displayed on a classic white LED dot matrix.

More power, more possibility

Power up your setup

Boasting 100 Watts per channel and compatible with a wide range of speakers, AXR100 comes with two sets of high-quality speaker outputs and a dedicated subwoofer output for the option of added bass.

Wired for sound

Perfect for music lovers across all genres, this receiver features 3 RCA input pairs, a built-in phono section, and a pair of recording outputs. A digital coax input and two optical connectors ensure flexible connectivity.

Made for vinyl

Plug a turntable straight into one of the analogue RCA inputs to enjoy your favourite records. With a built-in phono stage and moving magnet compatibility, listening to vinyl has never been easier.

Designed for more

With an eye on the future, the AXR100 shares the minimalist, timeless aesthetic of our AX Series in the classic 430mm width, fitting flawlessly into other systems while allowing for smooth progression up our range.

Technical specification

Manual

Power output

100 watts (into 8Ω)

Thd (unweighted)

<0.01% @ 1kHz, 80% of rated power <0.15% 20Hz - 20kHz, 80% of rated power

Frequency response (-1db)

5Hz - 50kHz

S/n ratio (ref 1w)

>82dB (unweighted)

Input impedances

47k ohms

Power amp damping factor

>50

Standby power consumption

<0.5W

Max. power consumption

550W

Bass/treble controls

Shelving, ultimate boost/cut +/- 10dB @ 100Hz and 20kHz

Subwoofer output

200Hz 2nd order L+R Level follows volume setting

Digital inputs

PCM 16-24-bit S/P DIF Co-axial 32-192kHz TOSlink Optical 32-192kHz

Dimensions

110 x 430 x 340mm (4.3 x 16.9 x 13.4”)

Weight

8.1kg (17.8lbs)

Bluetooth

5.0 A2DP/AVRCP supporting SBC

Tuner bands

European AM (522-1629kHz) FM (87.5-108MHz) / AM (540 - 1700kHz) FM (88 - 108MHz)

Aerial inputs

FM 75 ohms, Coaxial. AM 300 ohms wire loop/ single wire

Signal to noise (tuner)

60dB typical (FM)

Distortion (tuner)

<0.4% @ 1kHz 50kHz deviation (FM mono) <0.6% @ 1kHz 50kHz deviation (FM stereo)

In the box

AXR100 Stereo Receiver, Power Cable, Remote Control, 2 x AAA Batteries, FM antenna, AM antenna
